Smart Standing Frame

SKU: SMART 2 Category:

SMART™ Stander by Akces-Med is a sturdy upright standing frame that provides many benefits for both the client and carer because it enables a person to adopt an upright position which is safe and comfortable and highly supportive. Both chest and pelvic braces adjust to a person’s body to assist with an upright position with generous room for growth, sizing and adjustment options.

Smart Stander is suited to a range of conditions including brain and spinal cord disorders and trauma; cerebal palsy; and other degenerative or genetic conditions that require rehabilitation or permanent orthopaedic support.

Smart Stander is made from quality steel and timber construction with specially designed casters that make for easy transfers and a sturdy, large tray to maximise . Adjustments can be made quickly and easily with one allen key and the tray folds down for compact storage.

Key Features

  • Sturdy frame made with quality steel and timber construction.
  • 3-D Knee support adjustable in 3 directions to provide more comfort during use.
  • Footplate with adjustable sandals for stabilisation.
  • Adjustable pelvic and chest belts with a range of adjustment options.
  • Castors and brakes.
  • Tray that is generous in size and flexible in use. It folds away for easy storage.

Options

  • Soft cover for tray.
  • Available in 7 different sizes that cater to a range of sizes and maximum weight of 95kg.
SYMBOL UNIT Size 0a Size 1 Size 1a Size 2 Size 2a Size 3 Size 3a Size 4
A (cm) 22 22 28 28 37 37 44 44
C (cm) 18-44 18-65 24-68 28-86 28-92 30-107 30-110 33-129
A1 (cm) 20 20 26 26 35 35 42 42
C1 (cm) 41-56 58-76 55-80 70-96 72-107 86-121 86-126 106-145
Max. user weight (kg) 35 35 55 55 75 75 95 95

MEASUREMENT UNIT 0a 1 1a 2 2a 3 3a 4
Width (cm) 50 50 60 60 70 70 78 78
Length (cm) 63 63 70 70 87 87 91 91
Height (cm) 55 70 70 75 75 92 92 110
Weight (kg) 10 10 12 13 19.8 20 24.4 26

Note:  Measurement tolerance range is +/- 1cm
